Bench Ovens, Analog
SKU Description Capacity Temperature Range Electrical Quantity Price Add to Cart
21-250 Model 21-250 Bench Ovens, Analog, Aluminized Interior 7 cu ft +25 to 300°F 115V 50/60Hz 1 Each
$2,325
$2,120
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
21-250-1 Model 21-250-1 Bench Ovens, Analog, Aluminized Interior 7 cu ft +25 to 300°F 230V 50/60Hz 1 Each
$2,375
$2,161
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
21-250S Model 21-250S Bench Ovens, Analog, Stainless Steel Interior 7 cu ft +25 to 300°F 115V 50/60Hz 1 Each
$2,685
$2,370
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
21-350 Model 21-350 Bench Ovens, Analog, Aluminized Interior 7 cu ft +25 to 450°F 120V 50/60Hz 1 Each
$2,420
$2,198
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
21-350-1 Model 21-350-1 Bench Ovens, Analog, Aluminized Interior 7 cu ft +25 to 450°F 230V 50/60Hz 1 Each
$2,470
$2,240
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
21-350S Model 21-350S Bench Ovens, Analog, Stainless Steel Interior 7 cu ft +25 to 450°F 120V 50/60Hz 1 Each
$2,780
$2,495
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
31-350 Model 31-350 Bench Ovens, Analog, Aluminized Interior 10.6 cu ft +25 to 450°F 120V 50/60Hz 1 Each
$2,690
$2,568
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
31-350-1 Model 31-350-1 Bench Ovens, Analog, Aluminized Interior 10.6 cu ft +25 to 450°F 230V 50/60Hz 1 Each
$2,740
$2,609
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
31-350S Model 31-350S Bench Ovens, Analog, Stainless Steel Interior 10.6 cu ft +25 to 450°F 120V 50/60Hz 1 Each
$3,110
$2,914
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
51-550 Model 51-550 Bench Ovens, Analog, Aluminized Interior 6.6 cu ft +25 to 550°F 230V 50/60Hz 1 Each
$2,625
$2,551
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
51-550S Model 51-550S Bench Ovens, Analog, Stainless Steel Interior 6.6 cu ft +25 to 550°F 230V 50/60Hz 1 Each
$2,985
$2,869
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...

Description

Quincy Lab bench series ovens have been the workhorse in the industry for over 40 years. Now these timetested bench ovens are even better. A redesigned chamber and air flow distribution system, improved cabinet insulation, make the bench series an easy choice for heating applications everywhere.

Application

Developed for the industrial lab, these rugged general-purpose ovens are perfect for: preheating, thermal testing, self-batch processing, part drying, curing, baking, evaporating, or dehydrating various media, soils or aggregate, and many other applications. All models feature large work spaces and excellent portability. They can be moved to the job, or stacked on one another to conserve space. Wherever thermal processing is needed, the bench series ovens bring year after year of troublee-free service and performance.

Design Standards

A virtual non-contact exterior to interior cabinet design and highdensity industrial thermal fiber insulation greatly reduce thermal conductive transfer. That means greater energy efficiency and lower exterior wall temperatures. Refinements in the air plenums and mixing chamber deliver an evenly heated horizontal circular flow of air for rapid heat to part transfer. A reliable quick-sensing hydraulic thermostat balances good temperature stability with recovery performance. Heavy-duty chrome plated wire shelves can support 80 lbs. and can be spaced on 1.5" centers to provide up to 56 square feet of shelf surface (31-350). Cabinet exteriors are finished in our exclusive Q-Lab "high-tech" bronze polyester. Large high-impact thermal plastic door handles always remain cool to the touch.

Featuring

  • Large Bench or Portable Capacity
  • All Encompassing Circular Air Flow
  • ER Model Programmable PID Control
  • 80 lb Capacity shelves
  • Rapid Run-Up And Recovery
  • Proven Reliability
  • Full 18 Month Factory Warranty

Specifications

Model 21-250 21-350 31-350 51-550
Exterior Dim. 33"w x 24"h x 35.5"d 33"w x 24"h x 35.5"d 33"w x 34"h x 35.5"d 33"w x 24"h x 35.5"d
Interior Dim. 25.5"w x 19.75"h x 24"d 25.5"w x 19.75"h x 24"d 25.5"w x 30"h x 24"d 25.5"w x 19.75"h x 22.5"d
Capacity 7 cu ft 7 cu ft 10.6 cu ft 6.6 cu ft
Temperature Range Ambient +25°F to 300°F Ambient +25°F to 450°F Ambient +25°F to 450°F Ambient +25°F to 550°F
Max Shelves (1.5 inch centers) 11 11 17 11
Max Pounds per Shelf 80 80 80 80
Unit Weight 165 LBS 165 LBS 200 LBS 170 LBS
Shipping Weight 185 LBS 185 LBS 225 LBS 195 LBS
