Digital Air Forced Convection Ovens (Low Temp)
SKU Description Capacity Temperature Range Exterior Dimensions Electrical Quantity Price Add to Cart
10AFE-LT Digital Forced Air Oven (Low Temp) 0.6 cubic feet Ambient +15 to 225°F 14.0 x 20.5 x 12.3 in 115 V, 3.65 A, 440 W 1 Each
$1,244
$1,016
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
20AFE-LT Digital Forced Air Oven (Low Temp) 1.14 cubic feet Ambient +15 to 225°F 15.0 x 25.0 x 15.3 in 115 V, 3.65 A, 440 W 1 Each
$1,356
$1,161
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
30AFE-LT Digital Forced Air Oven (Low Temp) 1.83 cubic feet Ambient +15 to 225°F 20.0 x 29.9 x 14.3 in 115 V, 4.8 A, 800 W 1 Each
$1,478
$1,400
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
40AFE-LT Digital Forced Air Oven (Low Temp) 2.86 cubic feet Ambient +15 to 225°F 20.0 x 35.0 x 16.3 in 115 V, 6.8 A, 800 W 1 Each
$1,687
$1,631
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...

Description

Features

  • Digital microprocessor control
  • Durable double-wall construction
  • Scratch-resistant hammer finish
  • Corrosion-resistant aluminized interiors
  • Proven realiability
  • Full 18-month factory warranty

Advanced Design

Cabinets are as attractive as they are durable. Exteriors are painted light gray and have a hard, scratch-resistant hammer finish. Doors open with high-impact thermoplastic handles. Cabinets have heavy steel double-wall construction. Work space is insulated from the outer cabinet with one inch of high-desnity mineral wool, and interiors are made of corrosion-resistant aluminized steel.

Controls

The digital control combines the features of the analog model but offers the ease of temperature setting and the stability of a full PID microprocessor that accurately maintains settings within +/- 0.5 °C (1 °F), even in varying ambient or power supply conditions. A temperature-tracking feature stores temperature deviation from set point. This feature helps to confirm stability or indicate any control malfunction or power loss thorougout a process period. The digital controller features large LEDs that continuously display set temperature and process temperature, as well asa setting lock mode that provides protection against accidental or inadvertent adjustment.

Heating Elements

Energy-efficient, low-watt density incoloy sheathed elements are engineered into a compact design for quick run-up and recovery times. Temperature uniformity is greatly improved by a perforated heat shield which absorbs radiant heat and distributes it more evenly.

AFE-LT Series

The AFE-LT series offers forced air circulation for a uniform distribution of heat across the chamber, which facilitates dehydration and evaporation. The AFE-LT series has a temperature maximum of 225 °F / 107 °C, are competitively priced, and offer exceptional value and reliability.

Specifications

Model 10AFE-LT 20AFE-LT 30AFE-LT 40AFE-LT
Interior Dimensions (in) 12x8.25x10 13x11x13 18x14.2x12 18x19.8x14
Interior Dimensions (cm) 30.5x21x25.4 33x28x33 45.7x36x30.5 45.7x50.3x35.6
Exterior Dimensions (in) 14x20.5X12.3 15x25x15.3 20x29x14.3 20x35X16.3
Exterior Dimensions (cm) 35.6x52x31.2 38x63.5x38.9 50.8x73.7x36.2 50.8x89x41.4
Capacity (cubic ft) 0.6 1.14 1.83 2.86
Capacity (liters) 17 32.3 51.8 81
Temperature Range (° F) Ambient +15 °F to 225 °F Ambient +15 °F to 225 °F Ambient +15 °F to 225 °F Ambient +15 °F to 225 °F
Temperature Range (° C) Ambient +15 °F to 107 °C Ambient +15 °F to 107 °C Ambient +15 °F to 107 °C Ambient +15 °F to 107 °C
Max Shelves per Unit 8 11 14 20
Max Pounds per Shelf 35 35 35 35
Electrical 115V, 3.65A, 440W 115V, 3.65A, 440W 115V, 4.8A, 800W 115V, 4.8A, 800W
Plug Type 5-15P 5-15P 5-15P 5-15P
Unit Weight (lbs) 37.2 58.7 64.2 80.8
Shipping Weight (lbs) 50.4 65.7 84.2 98.5
Control Stability @ 75° C +/- 0.8 °C +/- 0.8 °C +/- 1.0 °C +/- 1.0 °C
Time to Max from Ambient 36 minutes 40 minutes 27 minutes 40 minutes
